Short fibers geotextileThe cotton fibers are processed using a carding machine or waste cotton unwinding machine to form a cotton web. This web is then arranged in a cross way or directly formed into a disorderly arrangement using an air flow web forming machine. This ensures that the fabric has an isotropic structure. Next, a group or groups of needle plates, consisting of numerous needles, are employed to needle the fiber web. This process intertwines the fibers and compresses them together, resulting in the formation of a fabric.nonwoven fabricThis approach is appropriate for the production of a dense and bulky geotextile with a thick structure, excellent water absorption and permeability, and high resistance to deformation. It is specifically well-suited for filtration and drainage projects that require significant thickness and durable performance. By employing this method, the resulting geotextile exhibits the desired characteristics for efficient water filtration and drainage applications.
Staple fibre needle punched geotextileThe production of non-woven fabric typically involves the use of brief polypropylene or polyester fibers. To create an alternative content that is closely related to the initial details, the generated text should be rearranged appropriately to convey the same message.Polypropylene geotextileWith its excellent cost/weight ratio, acid and alkali resistance, high strength, and wide application, this material offers superior chemical stability.
BPM short fiber nonwoven geotextileGeotextile is an incredibly versatile material that is commonly utilized for various purposes, including ground support and soil stability, landfill, river, dam, highway and railway construction, among others. Thanks to its exceptional qualities, such as high tensile strength, good wear resistance, excellent filtration, high elongation, and superior ultraviolet stability, geotextile has become an indispensable tool in many industries. Whether you need to reinforce a slope, prevent soil erosion, or filter water, geotextile is a reliable and cost-effective solution that can help you achieve your goals. So if you're looking for a durable and efficient way to manage your civil engineering or environmental projects, consider using geotextile and enjoy its numerous benefits.
| Test | Units | BPM100 | BPM150 | BPM200 | BPM250 | BPM300 | BPM350 | BPM400 | BPM450 | BPM500 | BPM600 | BPM800 | |
| Mechanical Properties | Tensile Strength | kN/m | 2.5 | 4.5 | 6.5 | 8 | 9.5 | 11 | 12.5 | 14 | 16 | 19 | 25 |
| (MD and XMD) | |||||||||||||
| Trapezoidal | |||||||||||||
| Tear Strength ≥ | kN | 0.08 | 0.12 | 0.16 | 0.2 | 0.24 | 0.28 | 0.33 | 0.38 | 0.42 | 0.46 | 0.6 | |
| (MD and XMD) | |||||||||||||
| CBR Burst | kN | 0.3 | 0.6 | 0.9 | 1.2 | 1.5 | 1.8 | 2.1 | 2.4 | 2.7 | 3.2 | 4 | |
| Strength ≥ | |||||||||||||
| Weight | g/m2 | 100 | 150 | 200 | 250 | 300 | 350 | 400 | 450 | 500 | 600 | 800 | |
| Weight Variation | % | -8 | -8 | -8 | -8 | -7 | -7 | -7 | -7 | -6 | -6 | -6 | |
| Thickness | mm | 0.9 | 1.3 | 1.7 | 2.1 | 2.4 | 2.7 | 3 | 3.3 | 3.6 | 4.1 | 5 | |
| Width Variation | % | -0.5 | |||||||||||
| Elongation at Break | % | 25 ~ 100 | |||||||||||
